Air Quality Starter Bundle
Product Number: BWIAQ1WA
Install Once. Upgrade Forever.
Keep the air in your home fresh and healthy with the Swidget Air Quality Starter Bundle. Wire our Auxiliary Control Switch to your ERV* or bathroom fan to activate automatic air exchanges when indoor air quality declines in your home.
- Controls your ERV* to enable automatic air exchanges when indoor air quality declines.
- Monitor indoor air quality in two separate locations in the home.
- Works with Panasonic Intellibalance Series of ERVs and most bathroom fans. User Manual
Instructions
Product Data Sheets
Regular price
$199.99 USD
Regular price
Sale price
$199.99
Unit price
per
0
40232207548494
Keep the air in your home fresh and healthy with the Swidget Air Quality Starter Bundle. Wire our Auxiliary Control Switch to your ERV* or bathroom fan to activate automatic air exchanges when indoor air quality declines in your home.
- Controls your ERV* to enable automatic air exchanges when indoor air quality declines.
- Monitor indoor air quality in two separate locations in the home.
- Works with Panasonic Intellibalance Series of ERVs and most bathroom fans. User Manual
Instructions
Product Data Sheets
| Product Name | Swidget 15A Outlet |
| Product Number | R1015SWA (W=white) |
| Input Power Rating | 125VAC, 15A |
| Outlet Receptacle Configuration | NEMA 5-15R |
| Resistive Load Rating | 1800W |
| Motor Load Rating | 0.5HP |
| Inductive Load Rating | 8A@125VAC (PF 0.4) |
| Relay Mechanical Endurance Rating | 1,000,000 cycles (or 274 years @ 10 cycles per day) |
| Wiring Type | Pre-stripped wire leads (Line/Neutral) #14 AWG (Stranded), Ground screw |
| Testing and Code Compliance | UL498 / UL1310, CSA C22.2 #42, #223 (Canada and US) |
| Flammability | UL94 5VA |
| Environmental | Indoor installation only |
| Operating Temperature | 14F to 104F (-10C to 40C) |
| Insert Voltage Output | Nominal 5VDC (+/- 5%) |
| Insert DC Protection | CLASS 2 - Current limiting and thermal shutdown protection |
| Insert Current Output | Constant current maximum 2.0A |
| Product Name | Swidget Auxiliary Control Switch |
| Product Number | S16009WA (W=white) |
| Input Power Rating | 125VAC, 5A |
| LED/CFL Load Rating | 300W |
| Incandescent Load Rating | 600W |
| Horsepower Load Rating | 0.3 HP |
| Wiring Type | Pre-stripped wire leads (Line/Neutral/Switch) #16 AWG (Stranded), Ground screw |
| Switch Configuration | Single pole, dry contact |
| Testing and Code Compliance | UL1310/UL60730-1 CSA 22.2 #223/E60730-1 (Canada and US) |
| Flammability | UL94 5VA |
| Environmental | Indoor installation only |
| Operating Temperature | 14F to 104F (-10C to 40C) |
| Insert Voltage Output | Nominal 5VDC (+/- 5%) |
| Insert DC Protection | CLASS 2 - Current limiting and thermal shutdown protection |
| Insert Current Output | Constant current maximum 2.0A |
| Product Name | Swidget Wi-Fi Control + Air Quality Insert |
| Product Number | WI008UWA (W=white) |
| Wireless Standard | Wi-Fi 802.11g |
| Wireless Band | 2.4 Ghz |
| Device Compatibility | Amazon Alexa, Google Assistant and IFTTT |
| Device Upgrades | OTA |
| Temperature Range | -10 - 40 °C (+/- 1 °C {after calibration}) |
| Relative Humidity Range | 0-100% (+/- 5% RH) |
| Air Pressure | 300 - 1100 hPa (+/-2hPa) |
| Calculated IAQ | 0 - 500 |
| Calculated TVOC | 0- 1000 ppb (TBC) |
| Calculated eCO2 | 400 - 6000 ppm (TBC) |
| Environmental | Indoor installation only |
| Operating Temperature | 14F to 104F (-10 °C to 40 °C) |
